Color/Finish |
Body |
Color |
Black |
Size/Weight |
Dimensions |
Width |
1017 mm |
Height |
139 mm |
Depth |
431 mm |
Gewicht |
Gewicht |
11.5 kg |
Control Interface |
Keyboard |
Number of Keys |
61 |
Typ |
Organ (FSB), Initial Touch |
Touch Response |
Normal, Soft 1, Soft 2, Hard 1, Hard 2 |
Other Controllers |
Joystick |
Yes |
Control Knobs |
2 (assignable) |
Display |
Typ |
TFT Color Wide VGA LCD |
Size |
800 x 480 dots (7 inch) |
Touch Screen |
Yes |
Color |
Color |
Language |
English, German, French, Spanish, Italian |
Panel |
Language |
English |
Voices |
Tone Generation |
Tone Generating Technology |
AWM Stereo Sampling |
Polyphony |
Number of Polyphony (Max.) |
128 |
Preset |
Number of Voices |
986 Voices + 41 Drum/SFX Kits |
Featured Voices |
131 S.Art!, 30 Mega Voice, 31 Sweet! Voices, 74 Cool! Voices, 89 Live! Voices, 24 Organ Flutes! |
Compatibility |
XG |
Yes (for Song playback) |
GS |
Yes (for Song playback) |
GM |
Yes |
GM2 |
Yes |
Expandability |
Expansion Voice |
Yes (approx. 400 MB) |
Editing |
Voice Set |
Part |
Right 1, Right 2, Right 3, Left |
Effects |
Types |
Reverb |
59 Presets + 30 User |
Chorus |
106 Presets + 30 User |
DSP |
322 Presets + 30 User |
Insertion Effect |
1-5: 322 Presets + 30 User |
Master Compressor |
5 Presets + 30 User |
Master EQ |
5 Presets + 30 User |
Part EQ |
28 Parts |
Others |
Mic/Guitar effects: Noise Gate x 1, Compressor x 1, 3Band EQ x 1 |
Arpeggio |
Yes |
Accompaniment Styles |
Preset |
Number of Preset Styles |
400 |
Featured Styles |
353 Pro Styles, 34 Session Styles, 10 DJ Styles, 3 Free Play |
Fingering |
Single Finger, Fingered, Fingered On Bass, Multi Finger, AI Fingered, Full Keyboard, AI Full Keyboard |
Style Control |
INTRO x 3, MAIN VARIATION x 4, FILL x 4, BREAK, ENDING x 3 |
Other Features |
One Touch Setting (OTS) |
4 for each Style |
Style Section Reset |
Yes |
Expandability |
Expansion Style |
Yes (Internal Memory) |
Compatibility |
Style File Format, Style File Format GE |
Songs |
Preset |
Number of Preset Songs |
5 Sample Songs |
Recording |
Number of Songs |
Unlimited (depends on the drive capacity) |
Number of Tracks |
16 |
Data Capacity |
Approx. 3 MB/Song |
Recording Function |
Quick Recording, Multi Recording, Step Recording |
Compatible Data Format |
Wiedergabe |
SMF (Format 0 & 1), XF |
Recording |
SMF (Format 0) |
Multi Pads |
Preset |
Number of Multi Pad Banks |
226 Banks x 4 Pads |
Audio |
Audio Link |
Yes |
Functions |
Registration |
Number of Buttons |
8 |
Control |
Registration Sequence, Freeze |
Playlist |
Number of Records |
2500 (max.) Records per Playlist file |
Lesson/Guide |
Lesson/Guide |
Follow Lights, Any Key, Karao-Key, Your Tempo |
Search |
Registration Bank |
Demo/Help |
Demonstration |
Yes |
Overall Controls |
Metronome |
Yes |
Tempo Range |
5 - 500, Tap Tempo |
Transpose |
-12 – 0 – +12 |
Tuning |
414.8 – 440 – 466.8 Hz |
Octave Button |
Yes |
Scale Type |
9 types |
Miscellaneous |
Direct Access |
Yes |
Text Display Function |
Yes |
Wallpaper Customization |
Yes |
Display Out |
Yes (by using a commercially available USB display adaptor) * For a list of compatible devices, access the “Yamaha Downloads” website. |
Voices |
Harmony/Echo |
Yes (with Arpeggio) |
Panel Sustain |
Yes |
Mono/Poly |
Yes |
Voice Information |
Yes |
Styles |
Style Creator |
Yes |
Style Recommender |
Yes |
OTS Information |
Yes |
Songs |
Song Creator |
Yes |
Score Display Function |
Yes |
Lyrics Display Function |
Yes |
Multi Pads |
Multi Pad Creator |
Yes |
Audio Recorder/Player |
Recording Time (max.) |
80 minutes/Song |
Recording |
.wav (WAV format: 44.1 kHz sample rate, 16 bit resolution, stereo), .mp3 (44.1 kHz sample rate,128/256/320 kbps, mono/stereo) |
Wiedergabe |
.wav (WAV format: 44.1 kHz sample rate, 16 bit resolution, stereo), .mp3 (MPEG-1 Audio Layer-3: 44.1/48.0 kHz sample rate, 64-320 kbps and variable bit rate, mono/stereo) |
Lyrics Display Function |
Yes (.mp3 only) |
Time Stretch |
Yes |
Pitch Shift |
Yes |
Vocal Cancel |
Yes |
Storage and Connectivity |
Storage |
Internal Memory |
Yes (approx. 1 GB) |
External Drives |
USB Flash Memory (via USB to DEVICE) |
Anschlüsse |
Headphones |
Yes |
FOOT PEDAL |
1 (SUSTAIN), 2 (ARTICULATION), Function Assignable |
Microphone |
Microphone/Guitar x 1 |
MIDI |
IN, OUT |
AUX IN |
Stereo mini jack |
LINE OUT |
MAIN OUTPUT (L/L+R, R) |
USB TO DEVICE |
Yes |
USB TO HOST |
Yes |
Amplifiers and Speakers |
Amplifiers |
15 W x 2 |
Lautsprecher |
13 cm x 2 + 5 cm x 2 |
Netzteil |
Netzteil |
PA-300C or an equivalent recommended by Yamaha |
Leistungsaufnahme |
21 W |
Auto Power Off Function |
Yes |
Accessories |
Included Accessories |
Owner's Manual, Online Member Product Registration, Music Rest, AC Adaptor |
