Amplifier + 9 effects
240
44.1 kHz
24-bit 128× oversampling
32-bit
20 Hz – 20 kHz (+1 dB/−2 dB) (10kΩ load)
5" TFT color LCD (800×480) Dot-matrix LCDs (128×32) (6)
Standard mono phone jack Rated input level: -20 dBu Input impedance (line): 500 kΩ
Standard mono phone jacks (2) Rated input level: -20 dBu Input impedance (line): 1 MΩ
Stereo mini jack Rated input level: -10 dBu Input impedance (line): 10 kΩ
Standard mono phone jack Maximum output level: INST/LINE +11.4 dBu/+19 dBu (when output impedance 10 kΩ or higher)
Standard stereo phone jack Maximum output level: Line +11.4 dBu (when output impedance 10 kΩ or higher) Headphones 24 mW + 24 mW (at 32Ω load)
Standard mono phone jacks (2) Maximum output level: Line +11.4 dBu (when output impedance 10 kΩ or higher)
123 dB
Left/Right : INST/LINE −99.5 dBu/−92.5 dBu
SEND: -99.0 dBu
5-pin DIN jacks
FP02M input
AC adapter: 12V DC, center plus, 2000 mA (ZOOM AD-19)
Connector: USB2.0 Type-C / Supported cable: Type-C cable GuitarLab: USB1.1 Full Speed Audio Interface: USB2.0 High Speed, 44.1 kHz/32-bit 4in 4out * Use cables for data transfer. USB bus power not supported.
Connector: USB2.0 Type-A / Standard: USB 2.0 High Speed * Use a USB thumb drive.
ZOOM BTA-1 or other dedicated wireless adapter
253 mm (D) × 495 mm (W) × 64 mm (H)
2.8 kg
* 0 dBu = 0.775 V
Open source notice (GPL) : This software includes open source software codes licensed under GNU General Public License. Details of the GNU GPL can be found at the GNU Website (External Link). The machine readable copy of the corresponding source code is available here.
